56-VOLT LITHIUM-ION CORDLESS BRUSHLESS STRING TRIMMER — ST1510/ST1510-FC 15
UNFOLDING THE SHAFT
WARNING:
In order to avoid
pinching your hands or ngers, do not
hold the shaft at the joint.
WARNING:
Do not attempt to
start the trimmer until the shaft has been
locked.
1. Remove the battery pack from the
trimmer.
2. Put your trimmer on the ground or
the oor and make sure that the
cable is inside the shaft, so that it
will not be pinched when closing
the hinge. Carefully unfold the shaft
until the two holes in the hinge are
accurately aligned (Fig. 2).
3. Insert the bolt (supplied) and tighten
it with the supplied hex wrench to
lock the shaft in place (Fig. 3).
MOUNTING THE GUARD
WARNING:
Always wear gloves
when mounting or replacing the guard.
Be careful of the blade on the guard and
protect your hands from being injured by
the blade.
1. Remove the battery pack from the
trimmer.
2. Lay the trimmer on the ground or
the oor with the trimmer head
facing upward.
3. Align the two screws, which are
preassembled on the guard, with
the two screw holes in the shaft
(Fig.4), and then tighten them with
the screwdriver (Fig.5).
2
4
3
5
