56-VOLT LITHIUM-ION CORDLESS BRUSHLESS STRING TRIMMER — ST1510/ST1510-FC22
1. Remove the battery pack from the
trimmer.
2. Cut one piece of cutting line 13 ft.
(4m) long.
3. Insert the line into the eyelet (Fig.17)
and push the line until the end of
the line comes out of the opposite
eyelet.
NOTICE: It is not necessary to align the
eyelets in order to insert the cutting line. If
the line cannot be inserted into the eyelet,
mount the battery pack onto the trimmer,
then press the line-loading button briey
to release the lower cover.
4. Remove the battery if it has been
mounted onto the trimmer in step 3.
5. Pull the line from the other side until
equal lengths of the line appear on
both sides of the trimmer head
(Fig. 18).
6. Install the battery pack onto the
string trimmer.
7. Press and hold the line-loading
button to start the line-winding
motor. The line will be wound into
the trimmer head continuously
(Fig. 19).
8. Watch the remaining line length carefully. Prepare to release the button as soon
as approximately 7 inches (17.8cm) of line are left on each side. Briey press
the line loading button to adjust the length until 5.5 inches (14cm) of the line is
showing on each side.
9. Push down on the Lower Cover Assembly while pulling on the lines to manually
advance the line in order to check for proper assembly of the cutting line.
17
Eyelet
Lower Cover
Cutting Line
18
Isometric Cutting Line
19
5.5" (14cm)
To Next Page
