2956-VOLT LITHIUM-ION ELECTRIC ZERO TURN MOWER — ZT4200L/ZT4200L-FC
TO ATTACH THE MULCHING PLUG (Sold separately)
1. To set up the mower for mulching, lift the side-discharge chute
rst, then hook the mulching plug onto the deck opening at the
spots 2, 3, and 4 as shown in Fig. 13. Make sure that all the
hooks are securely fastened in their places and prevent the
mulching plug from moving. Leave the side-discharge chute in
the open position.
2. To remove the mulching plug, separate the movable spring of
the mulching plug from the hook on the deck rst and then
remove it from the deck opening. Lower the side-discharge
chute slowly until it rests rmly against the deck.
3
2
1
4
13
Mulching PlugMovable Spring
Side Discharge Chute
