56-VOLT LITHIUM-ION ELECTRIC ZERO TURN MOWER — ZT4200L/ZT4200L-FC22
ASSEMBLY
WARNING: To prevent accidental starting that could cause serious personal injury, always remove the battery pack(s)
from the product when assembling parts, cleaning, or performing maintenance.
WARNING: If any parts are damaged or missing, do not operate this product until the parts are replaced. Use of this
product with damaged or missing parts could result in serious personal injury.
WARNING: Do not attempt to modify this mower or create accessories not recommended for use with this product.
Any such alteration or modication is misuse and could result in a hazardous condition leading to serious injury.
UNPACKING
WARNING: To reduce the risk of injury or mower damage, do not use a knife to cut the nylon straps. Use
scissors or side cutters.
WARNING
: To reduce the risk of damage, remove watches or other fragile and valuable items from your
wrists. There’s a risk of accidental contact with steel frame elements.
Recommended tools for unpacking (not included):
◾
Scissors or side cutters.
◾
Impact wrench with 1/2 in (13 mm) socket.
The EGO electric zero turn mower is shipped in a steel frame, with seat and steering levers separately packed in the steel
frame. The operator should remove the mower from the steel frame rst and then mount the seat and steering levers onto
the mower as follows:
1. Remove the plastic cover from the mower.
2. Cut the nylon straps and remove the accessory box located in the center seat area of the mower and remove the
two open-end wrenches inside.
3. Use the two supplied open-end wrenches to loosen all the bolts that secure the top frame, side frames, front frame,
back frame, and the two mower rear wheels from the bottom frame (Fig. 4). Remove and save the disassembled
frames in a safe area, avoiding tripping hazard. Consult your local waste authority for information regarding available
recycling and/or steel-disposal options on the frames.
NOTE: to simplify and speed up the process use an impact wrench with a 1/2 in (13 mm) socket.
