56V LITHIUM-ION CORDLESS SNOW BLOWER — SNT2400/SNT2400-FC 31

REPLACING THE AUGER

1. Remove the batteries.

2. Remove the two locking screws on

the top of the deck (Fig.27).

3. Remove the three ange screws

on both left and right of the deck

(Fig.28).

4. Remove the auger, together with

the gearbox as a whole set from

the deck. Then remove the ange,

bushing and gasket from the auger

shaft (Fig.29).

5. Remove the left and right shear pin

and separate the augers from the

auger shaft (Fig.30).

6. Replace the worn auger and

reassemble them in reverse order.

Flange Screw

Locking Screw

Flange

Gasket

Bushing

Gear Box

Auger

Auger Shaft

Shear Pin

Auger

Auger Shaft
