56-VOLT LITHIUM-ION CORDLESS 15" BRUSHLESS STRING TRIMMER22
Wind the spool with new line
WARNING:
To prevent serious personal injury, remove the battery pack from the
tool before servicing, cleaning, changing attachments or removing material from the unit.
1. Press the release tabs on the spool
base and remove the spool retainer
by pulling it straight out (Fig. 15).
2. Remove the spool. Use a clean cloth
to clean the inner surface of the
spool retainer and spool base.
NOTICE: Always clean the spool retainer,
spool base before reassembling the
trimmer head.
3. Check the spool retainer, spool and
spool base for wear. If necessary,
replace the wear parts.
4. Take approximately 17 ft (5.2m) of
new cutting line. Fold the line in half
and then adjust it so that one end is
4.5 in. (11cm) longer than the other
(Fig. 16).
5. Hook the folded end of the cutting
line onto either of the slots in the
spool (Fig. 17).
6. Wind the line, in two even and tight
layers, onto the spool. Wind the line
in the direction indicated on the
spool (Fig. 17).
NOTICE: Failure to wind the line in the
direction indicated will cause the trimmer
head to operate incorrectly.
16
4.5" (11 cm)
17
Wind Direction
15
Tab
