EGR RollTrac - Calibration Procedure

RT0001 Date: 08/04/20 Issue: 5 Page: 5 of 12
Calibration Procedure
PULL
2
1
L
O
C
K
A
C
C
O
N
S
T
A
R
T
P
U
S
H
4
3
10 SECONDS
!
START OF CALIBRATION
END OF CALIBRATION
1 2 3
4 5 6
2 SECOND PULSE
DURING CALIBRATION
• Cover will open and close twice automatically.
• The cover internal LED light will pulse slowly during calibration and stop pulsing when
calibration is complete.
1. Start the vehicle in an open area (note exhaust fumes are a health and safety hazard!).
2. Open the tailgate.
3. Ensure the motor clutch is engaged.
4. Ensure car doors are unlocked and disable auto-locking during calibration procedure.
Press the two side rail buttons simultaneously for 10 seconds to START calibration mode.
WARNING: Keep obstructions clear of cover during calibration mode.
