13
Preparation
Step 3 Connect the upper/lower seat:
Connect the upper and lower seat
with buffer balls.ȡ
Step 4 Wiring (very important):
Pay attention to the colors of cable ends and
make sure each one is connected to the right color or there may be damage
to the Gimbal.
Finished
GHOST red plug
GHOST black plug
Gimbal red plug
Gimbal black plug
Connect to the red plug
GHOST red cable to Gimbal
red cable
GHOST black cable to Gimbal
black cable
Connect to the black plug
GHOST red cable to Gimbal
blue cable
GHOST black cable to Gimbal
white cable
To Next Page
