11. Technical data
Electrical data:
Visualisation
Mechanical data:
Test standard
Voltage range 8-32V
Operating temperature -20°C to +70°C temporary discoloration of the display
Storage temperature -30°C to +80°C
Inputs Speed input for inductive encoder
Outputs Output for hydraulic valve 2A) semiconductor,
short-circuit protected
Total operating hours counter 0…99999 h
Daily operating hours counter 0…99:99 h
Speed measurement 1…5000 rpm
Pulses per rotation 1...60
Lower speed limit value 0...99% of normal speed
Restart speed 0...99% of normal speed
Display typ LCD
Resolution 32x128 Pixel
Background lighting yes
Display Black and white graphic display
Housing dimensions (L x W x H) 82 x 80 x 57 mm
Housing dimensions 7pin
(L x W x H)
82 x 80 x 100 mm
Housing dimensions 6pin
(L x W x H)
82 x 80 x 89 mm
Mounting dimensions (L x W x H) 82 x 80 x 77 mm ( with rubber-bonded metal )
Housing material ABS, PC (UV stabilized), light grey, Cover screw V2A
Weight 192g (without mounting connector)
Installation 4 x rubber-bonded metal, M4x10
Protection class IP54
Connection 7pin. Amphenol connector or
6pin AMP-CON-6 connector
Humidity DIN EN 60068-2-3
Vibration DIN EN 60068-2-6
Impact DIN EN 60068-2-27
EMV
DIN EN 61000-6-4, DIN EN 61000-4-20, DIN EN 61000-4-2, DIN EN
61000-4-3, DIN EN 61000-4-20, ISO 11451-1, DIN EN 61000-4-4, 61000-4-
5, DIN EN 61000-4-6
CE label according to directive 2014/30/EU
