Scope of delivery package
BSM 650 E,
Quick-change drill chuck 2 -13 mm,
Additional grip with bit stop
Description
1 Quick-change drill chuck
2 Depth stop
3 Additional handle
4 Selector button: drill/hammer
5 Selector button:
clockwise/anticlockwise
6 Speed control
7 Locking button
8 On/Off switch
Technical data
Voltage: 230 V ~ 50 Hz
Power rating: 650 W
Drilling capacity Concrete 13 mm
Steel 10 mm
Wood 20 mm
No Load Speed 0 - 2600 min
-1
Number of blows 0 - 26.500 min
Safety insulated
Sound pressure
level LPA 93,3 dB(A)
Sound power
level LWA 106,3 dB(A)
Vibration a
w
14,9 m/s
2
Weight 1,8 kg
Caution
The BSM 650 E is not desi-
gned for the operating of auxili-
ary devices.
Do not use near steams or
inflammable liquids.
Only use sharp bits and suita-
ble screwing bits.
Remove the plug from the
socket for all adjusting and
cleaning work.
Protect the mains cable against
any damage. Oil and acids can
damage the cable.
Do not carry the device by the
mains cable.
GB
7
