EINHELL GE-EC 2240 User Manual

GB
- 22 -
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains voltage: ...................220-240 V ~ 50/60 Hz
Power rating: ........................................... 2200 W
Idling speed: ......................................... 7800 rpm
Cutter rail length: .................................... 406 mm
Cutting length, max.: .............................. 375 mm
Cutting speed at rated rpm: .......................15 m/s
Oil tank capacity: .......................................150 ml
Weight with cutter rail and chain: ................5,6 kg
Protection class: ...........................................II /
쓑
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level ..................... 93,8 dB(A)
K
pA
uncertainty .............................................3 dB
L
WA
sound power level ........................ 107 dB(A)
K
WA
uncertainty .............................................3 dB
L
WA
sound power level guaranteed ....... 110 dB(A)
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 60745.
Front Handle under load
Vibration emission value a
h
= 3.46 m/s
2
K uncertainty = 1.5 m/s
2
Rear Handle under load
Vibration emission value a
h
= 5.89 m/s
2
K uncertainty = 1.5 m/s
2
The specifi ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specifi ed value
in exceptional circumstances.
The specifi ed vibration value can be used to
compare the equipment with other electric power
tools.
The specifi ed vibration value can be used for initi-
al assessment of a harmful eff ect.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
Caution: Do not connect the chainsaw to the po-
wer supply until it has been fully assembled and
the chain tension has been adjusted. Always wear
protective gloves when working on the chainsaw
to protect yourself against injury.
5.1 Assembly of the cutter rail and the saw
chain
•
Carefully unpack all parts and check that they
are complete (Fig. 2-3).
•
Undo the fixing screw of the chain wheel co-
ver (Fig. 4).
•
Take off the chain wheel (Fig. 5).
•
Lay the chain as shown in the groove which
runs around the cutter rail (Fig. 6/Item A).
•
Insert the cutter rail and chain as shown in
the mounting in the chainsaw (Fig. 6). At the
same time guide the chain around the chain
wheel (Fig. 6/ Item B).
•
Attach the chain wheel cover and secure it
with the fixing screw (Fig. 7). Caution: Do not
fully tighten the fixing screw until after adjus-
ting the chain tension (refer to point 5.2).
Anl_GE_EC_2240_SPK7.indb 22Anl_GE_EC_2240_SPK7.indb 22 09.07.2018 12:47:5609.07.2018 12:47:56
Autogoods “130”
130.com.ua

EINHELL GE-EC 2240 Specifications

General

Power source	AC
Chain speed	15 m/s
Product color	Black, Red

Weight and Dimensions

Width	215 mm
Height	275 mm
Length	530 mm
Weight	5600 g
