EINHELL RT-RH 32 User Manual

6
GB
 Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
1. Safety regulations
The corresponding safety information can be found
in the enclosed booklet.
 CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1)
1. Dust guard
2. Locking sleeve
3. Rotary switch for rotation stop facility
4. ON/OFF switch
5. Rotary switch for hammer stop facility
6. Additional handle
7. Depth stop
8. Drill bit – chisel set
9. Dust collection device
10. Drill bit grease
11. Handle
3. Proper use
The tool is designed for drilling with hammer action in
concrete, rock and brick, as well as for chiseling
work, always using the respective correct drill or
chisel bit.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains voltage: 230 V ~ 50 Hz
Power input: 1250 W
Idling speed: 800 rpm
Blow rate: 4300 rpm
Drilling capacity in concrete/stone (max.): 32 mm
Protection class: II / 쓑
Weight: 6.1 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level 92.3 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 103.3 dB(A)
K
WA
uncertainty 3 dB
The hammer drill is not designed for outdoors use as
specified I Article 3 of Directive
2000/14/EC_2005/88/EC.
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
Hammer drilling in concrete
Vibration emission value a
h
= 12.889 m/s
2
K uncertainty = 1.5 m/s
2
Chiseling
Vibration emission value a
h
= 15.939 m/s
2
K uncertainty = 1.5 m/s
2
 Important!
The vibration value changes according to the area of
application of the electric tool and may exceed the
specified value in exceptional circumstances.
Anleitung_RT_RH_32_SPK1:_ 01.12.2008 15:39 Uhr Seite 10

EINHELL RT-RH 32 Specifications

General

Cord length	4.45 m
Input power	1250 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Impact rate	4300 bpm
Rated speed (max)	800 RPM
Impact energy (max)	3.5 J
Drilling diameter in steel (max)	- mm
Drilling diameter in concrete (max)	12 mm
Soft grip	Yes
Chuck type	SDS Plus
Product color	Red
Power protection features	Overload

Weight and Dimensions

Width	135 mm
Height	340 mm
Weight	6050 g
Package weight	9450 g
