EINHELL TE-CD 18 Li User Manual

GB
- 7 -
Important!
-erp ytefas wef a ,tnempiuqe eht gnisu nehW
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Caution!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fi re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
2. Layout and items supplied
2.1 Layout (Fig. 1)
rotceles euqroT .1
2. Battery capacity indicator
3. Changeover switch
4. ON/OFF switch
5. Battery pack
6. Battery charger
7. Selector switch for 1st/2nd gear
8. Pushlock button
9. Quick-change drill chuck
10. LED lamp
11. LED display for counter-clockwise/clockwise
12. Removable holding clip
2.2 Items supplied
Please check that the article is complete as spe-
cifi ed in the scope of delivery. If parts are missing,
please contact our service center or the nearest
branch of the DIY store where you made your
purchase at the latest within 5 work days after
purchasing the article and upon presentation of
a valid bill of purchase. Also, refer to the warranty
table in the warranty provisions at the end of the
operating instructions.
•
-piuqe eht tuo ekat dna gnigakcap eht nepO
ment with care.
•
yna dna lairetam gnigakcap eht evomeR
packaging and/or transportation braces (if
available).
•
.deilppus era smeti lla fi ees ot kcehC
•
rof seirossecca dna tnempiuqe eht tcepsnI
transport damage.
•
litnu gnigakcap eht peek esaelp ,elbissop fI
the end of the guarantee period.
Important!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
revirdwercs/llird sseldroC
•
.oN .trA htiw deilppus toN( regrahc yrettaB
45.136.89)
•
)89.631.54 .oN .trA htiw deilppus toN( yrettaB
•
Original operating instructions
•
snoitcurtsni ytefaS
3. Proper use
-hgit rof dengised si revirdwercs/llird sseldroc ehT
tening and undoing screws, as well as for drilling
in wood, metal and plastic.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equi
valent purposes.
Anl_TE_CD_18_Li_Kit_SPK7.indb 19 04.06.13 12:04

EINHELL TE-CD 18 Li Specifications

General

Soft grip	Yes
Product design	Pistol grip drill
Number of gears	2
Torque settings	24
Screw diameter (max)	10 mm
Idle speed (1st gear)	320 RPM
Idle speed (2nd gear)	1350 RPM
Maximum torque (hard applications)	48 N⋅m
Product color	Black, Red
Number of batteries included	1 pc(s)
Power source	Battery
Charging time	30 min
Battery voltage	18 V
Battery capacity	1.5 Ah

Weight and Dimensions

Depth	420 mm
Width	105 mm
Height	335 mm
Weight	1500 g
