EIT Part Number: P/N IM-0110 Rev A Issued April 2019
Page 11
Appendix A MicroCure Product Specifications
MicroCure
®
Radiometer
UVA Spectral Response 320-390 nm
UVV Spectral Response 395-445 nm
Spectral Response Note
The MicroCure UVA and UVV bands are similar but not identical to the UVA
and UVV bands in other EIT instruments that are 0.5” in height
Suggested Operating (Dynamic)
Ranges
10 Watt (UVA or UVV): 500 mW/cm
2
to 10 W/cm
2
2 Watt (UVA or UVV): 100 mW/cm
2
to 2 W/cm
2
200 milliWatt (UVA): 10 mW/cm
2
to 200 mW/cm
2
The DataReader display will flash if the unit has over-ranged. Suggested
Operating Range provides the best instrument performance. MicroCure
units will “turn on” at lower irradiance values as shown below
Approximate Start Threshold
Values
The values listed below are the approximate required threshold values
needed to activate the MicroCure. Use a MicroCure with the correct
operating (dynamic) range.
10 Watt (UVA or UVV): +/- 50 mW/cm
2
2 Watt (UVA or UVV): +/- 10-15 mW/cm
2
200 milliWatt (UVA): +/- 1-2 mW/cm
2
Sample Rate/Smooth Mode
2048 samples per second. The MicroCure reports the peak “Smooth Off”
irradiance value and not the “RMS” or average irradiance value.
Peak Irradiance Accuracy +/- 7% @ 25°typical
-0.2% per 1°C over operating range
Total Energy 0-9999 Joules/cm². Display flashes if over-ranged.
Calibration Each MicroCure is supplied with a NIST traceable calibration certificate
Spatial Response Approximately cosine
Operating Temperature Range 15-70°C internal
Time-Out Period 4 minutes after last UV exposure
Batteries Permanent lithium cell
Expired units can be returned to EIT for proper battery disposal
Battery Life 200 readings or 1 year, whichever comes first
Dimensions 1.30" long x 1.0" wide x 0.25" high (33.0mm x 25.4mm x 6.4mm)
Weight 0.33 oz. (9.4 grams)
Materials Plated Aluminum/Nylon/ RoHS
Specifications subject to change without notice
