Panel Panel Size and Type 76 cm (29.8") TFT color LCD panel
Viewing Angles (H, V) 178°, 178° (at contrast ratio of 10:1)
Brightness / Contrast 260 cd/m
2
/ 900:1
On/Off Response Time 12 ms (typical)
Midtone Response
Time 6 ms
1
Native Resolution 2560 × 1600
2
Active Display Size (H × V) 641.3 × 400.8 mm
View
able Image Size Diagonal: 756 mm
Pixel Pitch 0.2505 × 0.2505 mm
Display Colors 16.77 million from a palette of 68 billion
Cabinet Color Blac
k
Dot Clock Digital: 269 MHz
Scanning Frequency (H, V) Digital: 31 – 100 kHz, 59 – 61 Hz
(VGA
Text: 69 – 71 Hz)
Input Signals Digital:
DVI Standard 1.0
Input Terminals DVI-D 24 pin × 2 (dual link × 1, single link
[HDCP supported
3
] × 1)
USB Port / Standard 1 upstream, 2 downstream / USB Standard
Rev. 2.0
Plug & Play VESA DDC 2B
Po
wer Power Requirements AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz
Power Consumption 170 W (maximum)
84
W (typical / AC100 V)
82 W (typical / AC200 V)
Power Save Mode Less than 2 W
Physical
Specifications
Height Adjustment Range 90 mm
T
ilt / Swivel / Pivot 30° Up, 3° Down / 35° Right, 35° Left / –
Dimensions (W × H × D) With Stand:
689 × 489.5 – 579.5 × 272 mm
Without Stand: 689 × 450 × 90 mm
Net Weight With Stand: 15.3 kg
Without Stand:
11.1 kg
Auto Brightness Function Auto Brightness Stabilization
Auto Po
wer Save Function Digital: DVI DMPM
Display Mode Options Fine Contr
ast (Text, Picture, Movie, sRGB, Cus-
tom, WindowMovie
4
), Auto Fine Contrast
5
Screen-
Manager OSD
Adjustment
Functions
Screen Adjustment Screen Size (full screen, enlarge, normal),
Smoothing (5 stages), Border Intensity
Color Adjustment Brightness, Independent 6-Color Control,
Gamma, Temperature (in 500 K increments
from 4,000 K – 10,000 K including 9,300 K),
Saturation, Hue, Gain, Reset
Power Save Settings Digital: PowerManager (DVI DMPM), Off Timer
Other Settings Signal Settings,
Product Information (product
name, serial number, resolution, operating
time), OSD Menu Settings, Adjustment Lock,
Languages (English, French, German, Italian,
Japanese, Simplified Chinese, Spanish, Swed-
ish, Traditional Chinese), Beep, Power Indicator,
Dual Display
6
, Reset
Certifications and Standards TCO’03, TÜV/Ergonomics (including ISO
13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus),
CSA (cTÜVus), FCC-B, Canadian ICES-003-B,
TÜV/S, VCCI-B, EPA ENERGY STAR
®
, RoHS,
WEEE, EIZO Eco Products 2006
Supplied Accessories AC power cord, signal cables (DVI-D – DVI-D,
DVI-D – DVI-D (dual link supported), USB cable,
EIZO LCD Utility Disk (PDF user’s manual,
ScreenManager Pro for LCD
7
, ICC Profile),
setup guide, 4 screws for mount option, war-
ranty registration card
Warranty Five Years
8
1
Average response time measured between each grayscale level of 31, 63, 95, 127, 159, 191, and 223.
2
A graphics
board that supports dual link is required for displaying 2560 × 1600 resolution.
3
Display with audio/video is not
supported.
4
WindowMovie mode is selectable only when Auto Fine Contrast is active.
5
Bundled ScreenManager Pro
for LCD is necessary to activate Auto Fine Contrast. Support for those functions varies with the graphics board used.
6
Dual 1200 × 1600 display is available with Dual Display mode.
7
ScreenManager Pro for LCD is compatible with the
Microsoft Windows 98SE/Me/2000/XP operating systems only.
8
The usage time is limited to 30,000 hours or less, and
the warranty period of the LCD panel and backlight is limited to three years from the date of purchase.
3 0 " C o l o r L C D M o n i t o r
Specifications12-Bit Gamma, 16-Bit Internal Processing
EIZO’s latest integrated circuit is buit in and features
a 12-bit look-up table with a color palette of 68 bil-
lion colors from which the most appropriate 16.7 mil-
lion (8-bits) are displayed. It also has 16-bit internal
processing for smooth display of grayscale tones,
especially in dark areas of an image.
Detailed Color Control
What good is a 30" screen for doing graphics work
without even the most basic color control functions?
W
ith the FlexScan SX3031W you can adjust not only
brightness, but also gamma, saturation, hue, gain and
color temperature. For fine-tuning of even a single
color
, the hue and saturation settings for RGBCMY
can be adjusted independently.
Dual DVI-D Inputs
Dual DVI-D inputs (digital) are included for con-
necting to two PCs. One input supports dual link for
displaying resolutions up to the monitor’
s maximum
of 2560 × 1600, and the other input is single link for
resolutions up to 1920 × 1200.
6 ms Midtone Response Time
A built-in overdrive circuit reduces midtone response
time to 6 ms. Fast video sequences and 3D-CAD ani-
mation are displayed without delays.
Scale Non-Native Resolutions to a Full Screen
When working at less than native resolution or aspect
ratios different than 16:10 you can use the scaling func-
t
ion to enlarge your work or even expand it to fill the
screen. This is especially useful when using the moni-
t
or’s single link input. You can then smooth or sharpen
the image in five increments.
Customer Assurance
A five-year warranty offers a long service life, and
compliance with leading industry standards such as
TCO’03 and TÜV Ergonomics ensures a better work-
i
ng environment. The EIZO Eco Products 2006 label
indicates these products meet strict internal require-
m
ents for design, manufacturing, packaging, and usage.
Dimensions
