EK-Quantum Vector2 Trio RTX 3080 - Nickel Acetal

- 7 -
NICKEL ACETAL
- Dimensions: (LxHxW): 334.5 x 155 x 27mm
- D-RGB LED count: 38
- D-RGB cable length: 50cm
- D-RGB connector 3-pin 5V digital LED header
Position EAN Description Quantity
1 104465 Coldplate (Nickel) 1
2 103974 Acetal Stand out 1
3 100663 EK - Badge 2
4 104211 Mylar sticker 2
5 8202
Screw M3x12 DIN7991 2
6 103947 FC Terminal 1
7 103968 Light guide 1
8 104469 Acetal top plate 1
9 104475 Backplate (Bl.elox) 1
10 103942 Terminal Badge 1
11 104216 Disc magnet 3x3 2
12 8311 Screw M4x20 DIN7984 3
13 104106 Terminal OR - 14x1 mm 2
14 103987 Standoff M3.5-M2.5 x 3 7
15 103988 Standoff M4-M2.5 x 3mm 4
16 103986 Standoff M3.5-M2.5 x 11.3mm 4
17 104187 Screw M2.5x8 AX1 7
18 104188 Standoff fi 4.5/2.5 7
19 9024 Screw M4x10 DIN7984 13
20 103962 Plexi insert 1
21 104296
LED D-RGB Dense Strip Double - 500/130mm 1
22 104484 Main O-ring 162 x 2 mm 1
23 104902 PCB cardboard 1
10
14
16
18
17
2
4
7
12
5
21
3
19
6
11
13
22
15
1
8
23
9
20
