Device menu
User Manual Biosen C_line Clinic / GP+
36
36
"Samples – double determination?"
If limits are exceeded during sample measurement, a second
measurement of this sample can be carried out (double
determination).
9.5 Date / Time
Setting of date and time.
9.6 Printer type
The serial printer DPU-414 is available.
9.7 EDP
This menu item contains all relevant parameters for connecting the
device with the hospital EDP. Changes should only be made by
competent personnel.
9.7.1 Protocol type
Here the structure of the transfer protocol can be set. The "BIOSEN"–
protocol is supported. For protocol structure see section 10.2.2, page 41.
9.7.2 Interface parameter
Adjustable Baud rates and parameters (length, start/stop, parity)
Possible Baud rates: 1200, 2400, 4800, 9600
Possible parameters: 8, 1, Even 7, 1, Even 7, 2, Even
8, 1, Odd 7, 1, Odd 7, 2, Odd
8, 1, No 7, 1, No 7, 2, No
9.7.3 Preamble / Postamble
Adjustable start and end identification code of the data protocol.
Possible preambles:
{CR}, {CR LF}, {STX}, {STX CR}, {STX CR LF}, {STX DEL}
Possible postambles:
{CR}, {CR LF}, {ETX}, {CR ETX}, {CR LF ETX}, {DEL ETX}
