Accessories and Connections
User Manual Biosen C_line Clinic / GP+
42
42
RFL
Results-Flag
No error
>= warning limit for sample
<= warning limit for sample
>= warning limit for controls
<= warning limit for controls
>= measurement range
<= measurement range
No value
1
1
1
1
1
1
1
1
0
1
2
3
4
5
6
7
MC
Measuring channel
Measuring channel 1
Measuring channel 2
1
1
0
1
POSTAMBLE
End of data block
1 to 4
see section 9.7.3 –p.36
With each measurement a complete data telegram is transmitted per
measuring channel. The distinction between them is made via the
telegram field MC. Hence for a 2-channel device two data telegrams are
transmitted with a gap of approx. 1000ms. If one measuring channel is
switched off on a 2-channel device, from that point on only one data
telegram per measurement is transmitted.
