EKO MS-80 User Manual

EKO INSTRUMENTS CO., LTD. - Pyranometer MS-80/80S/80U - Instruction Manual Ver. 1
Pg. 19
5- 4. Connections
The MS-80 and MS-80U have an analog output for irradiance and detector temperature measurements. The MS-
80S is based on a digital Smart processing interface providing advanced measurement functions with 4 different
industrial signal outputs (Modbus 485 RTU, configurable SDI-12, 4-20mA, configurable 0-10mA and 0-1V with
external precision shunt resistor 100Ω).
Table 5-5. Pyranometer outputs
Output
MS-80 MS-80S MS-80U
Analog (mV)
○
x
○
Modbus 485 RTU (Default)
x
○
x
SDI-12
x
○
x
4 - 20 mA (Default)
x
○
x
0 - 10 mA
x
○
x
0 – 1V
x ○
(*)
x
(*) MS-80S 0-10mA output with external precision shunt resistor
Table 5-6. Pyranometer output parameters
Output parameters
MS-80 MS-80S MS-80U
Irradiance
○ ○ ○
Temperature
○ ○
(*)
○
Tilt position
x
○
(*)
x
Relative humidity
x
○
(*)
x
Sensor information
x
○
(*)
x
(*) MS-80S digital output (Modbus 485 RTU / SDI-12)
