EKO INSTRUMENTS CO., LTD. - Pyranometer MS-80/80S/80U - Instruction Manual Ver. 1
Pg. 28
2. Pyranometer default settings
The MS-80 and MS-80U have an analog output for irradiance and detector temperature measuremests. The MS-
80S is based on a digital Smart processing interface providing advanced measurement functions with 4 different
industrial signal outputs (Modbus 485 RTU, configurable SDI-12, 4-20mA, configurable 0-10mA and 0-1V with
external precision shunt resistor 100Ω).
Where to find information regarding the MS-80 defaults settings and important parameters:
Table 5-9. MS-80 / 80U where to find the settings
MS-80 / 80U
Defaults setting and parameters
Sensitivity figure
 Calibration certificate
 Serial number label
Impedance
 Serial number label
Table 5-10. MS-80S where to find the settings
MS-80S
Defaults setting and parameters
Sensitivity figure
 Calibration certificate
 Modbus register
 SDI-12 register
Modbus 485 RTU (Default)
 Settings report (see appendix A-9 MS-80S settings report)
 Modbus register
o Address (last two digits of serial number, 100 if “00”)
o Baud rate 19200
o Parity Even
SDI-12
 Settings report
 SDI-12 register
o Address 0
o Baud rate 1200
o Parity Even
4 - 20 mA (Default)
 Settings report
o 4-20mA = 0 – 1600W/m2
0 - 10 mA
 Settings report
o 0-10mA = 0 – 1600W/m2
0 – 1V
 Settings report
o 0-1V = 0 – 1600W/m2
