Impression 444 – Owner's manual
17
39. Genoa sheet cam cleats
40. Waste tank dockside
suction
41. Front coachroof
windshield
42. Cockpit table sink
43. Cockpit table storage
Compass
44. Fixed portlight
45. Cockpit drink holed
46. Spring cleat
47. Handle
48. Shore power socket
49. Gas locker
50. Engine panel
Keep portlights, windows, washboards, doors, hatches and ventilation
openings closed when appropriate, e.g. in rough weather or at higher
sailing speeds.
Secure unfixed equipment safely when underway.
If a liferaft shall be fitted, recommended place is on the deck in front of
the mast.
If a liferaft is fitted please strictly follow instructions of liferaft
manufacturer.
In case if somebody falls overboard, use swimming ladder fitted on the aft
to climb back.
5.2. INTERIOR LAYOUT
Following picture shows standard layout (version 1). For other versions of the interior please
check the layouts in the annexes.
Figure 4
1. Aft cabin - port
2. Companionway / engine
3. Central head
4. Saloon
5. Forward cabin
6. Anchor locker
7. Aft cabin – stb
8. Navigation table
9. Galley
10. Shower
11. Forward head
12. Forward double bunk cabin
13. Stern transom volume
