Impression 444 – Owner's manual
26
NEVER use the waste water pump with the outlet seacock closed.
NEVER use any other but thin absorbent toilet paper and never too much.
Any other kind may damage the pump.
Follow carefully the instructions for use and precautions marked on the
pump.
If the pump breaks down, it will have to be taken apart and cleaned.
The mechanism is maintained by rinsing the whole system with fresh
water. This is done by operating the pump.
NOTE: Observe local regulations on discharge!!!
Figure 11
1. Toilet with manual pump
2. Toilet sea inlet
3. Toilet sea inlet seacock
4. Toilet waste outlet hose
5. Toilet waste outlet seacock
6. Waste water Y valve
7. Waste water tank - 130 l
8. Macerator waste pump
9. Waste outlet from macerator
10. Waste outlet seacock
11. Waste tank ventilation hose
12. Waste tank odor filter
13. Waste tank ventilation
14. Waste tank marine outlet
15. Waste tank inspection
16. Level indicator
7.4. BILGE WATER SYSTEM
The bilge strainer is located under the saloon floor. Lifting the boards in front of the
companionway will allow you access to the bilge pump via a bilge strainer.
