Impression 444 – Owner's manual
37
CAUTION:
It is recommended to disassemble the steering mechanism every two
years to lubricate it and thoroughly check the rudder blade.
Clean the bearings and when reassembling, lubricate them with a
lubricant resistant to sea water.
Figure 16
1. Rudder blade
2. Rudder stock
3. Guiding tube
4. Quadrant
5. Emergency tiller
6. Quadrant stopper
7. Cover
