Industrial Edge Computing Gateway EG500
ELASTEL TECHNOLOGY CO., LTD.
WWW.ELASTEL.COM
Antenna
4G: inside SMA x 1、WiFi/Buletooth: inside SMA x 1, LoRa/WiFi Halow:
inside SMAx1
Industrial Serial Port
RS-232 x 1, RS-485 x 1;
RS-232 signal: TXD, RXD, GND; RS-485 signal: A, B, GND; ESD protection:
15KV
I/O
6-channel digital input DI
(0..24VDC, Configurable Status/Count mode)
3-channel Analog input AI
(0-10V DC, 4-20mA, 18-bit resolution)
6-channel digital/pulse output DO
(0..60V, Max. power 6fficiency: 500 mA)
USB
USB 2.0 x 2 for peripherals,
USB-C x 1 for Console
HDMI
HDMI 2.0 x 1, (Up to 4kp60 video & audio output)
Reset Button
Supported
Power
Power supply
Wide Range Voltages 9~36V DC/1A, recommended 24V/1.5A
Power Terminal
Unpluggable industrial terminal connection
Power consumption
Less than 10 W (system)
Power Output
2-channel power supply for slave devices, same value as Power input (24V)
Mechanical features
Protection
IP30
Housing
Aluminum Heatsink
Cooling
Fanless cooling
Dimensions (cm)
187mm x 112mm x 42mm
Installation
DIN-rail, wall mounting
Weight
790g
Ambient temperature and humidity
Storage temperature
-30 ~ 75°C
Ambient humidity
5 ~ 95% (non-condensing)
Operating temperature
-25 ~ 70°C (industrial grade)
EMC index
Static electricity
level 3
Radiated electric field
level 3
Surge
level 3
Others
LED Indicator
1-POWER, 1-WiFi, 1-SYSTEM, 1-ALARM,1-ONLINE, 3-Signal Strength
Watchdog
Standalone Hardware Watchdog
Warranty
Standard 12 Months
Software Features
OS
Optimized OpenWRT V21 with SDK /Raspbian
Configuration
WebUI, Local CLI, Remote configuration
