Industrial Edge Computing Gateway EG500
ELASTEL TECHNOLOGY CO., LTD.
1. Product Introduction
1.1 Overview
The Elastel EG500 is an industrial high-performance Edge Computing Gateway for IoT applications.
Powered by Raspberry Pi CM4, expanded common I/O ports and various networks to support IoT
needs. With rugged, fanless enclosure design. The truly IPC-grade EG500 is used as an IoT gateway,
edge device, or customizable industrial controller… for today’s industrial and embedded applications.
1.2 Features
Powered by Raspberry Pi industrial compute module 4 (CM4), up to 8GB RAM and 32GB eMMC
Built-in dual mini-PCIe sockets for 4G LTE, and LoRaWAN
Reserved SX-NEWAH module for WiFi HaLow (802.11ah) connectivity
Isolated DI/DO/AI/RS232/RS485 interfaces
Embedded watchdog for work stability
Aluminium chassis Fanless cooling design for rugged structural
and wide operating temperature -25~70℃
Fully compatible with Raspbian, OpenWRT, Ubuntu OS, etc.
1.3 Specifications
Broadcom BCM2711, Quad-core A72 (ARM v8)@ 1.5 GHz
2GB (2GB/4GB/8GB optional) LPDDR4
8GB (16GB/32GB optional) eMMC
2x Gigabit Ethernet, (1-WAN+1-LAN or 2-LAN Configurable)
4G LTE, 3G, 2G, NB-IoT, CAT-M1
Dual Band 2.4GHz & 5GHz + Bluetooth 5.0
Supported (Optional, reserved mPCIe for LoRaWAN module)
WiFi HaLow (802.11ah WiFi)
Supported (Optional, reserved SX-NEWAH module for WiFi HaLow)
Cellular Module built-in supported (Optional)
1.8 V/3 V; drawer-type Nano card holder × 1
