Elation DARTZ 360 - System Menu Options - Part 1; Receive Menu Functions; Function Menu Settings

15 www.elationlighting.com
ELATION© DARTZ 360™
S Y S T E M M E N U
Features are subject to change without any prior written notice.
Supports Software Versions: ≥ 1.1.5
MAIN MENU
SUB MENU
OPTIONS / VALUES (Default Settings in BOLD)
DESCRIPTION
Receive
Set Address
001 ~ XXX
DMX Address Setting
User Mode
User Mode
Basic (19 Channel)
Standard (22 Channel)
Extend (25 Channel)
User A
User B
User C
Set DMX Channel / User Mode
Edit A
Max. Chan
:
Dim Modes
Edit User Defined
Channel Assignments
Edit B
Edit C
Function
Status
NoDMX Mode
Hold / Auto / Blackout
Function If NO DMX Detected
P.Reverse
ON / OFF
Pan Reverse Movement
T.Reverse
ON / OFF
Tilt Reverse Movement
Pan Degree
630/540
Pan Degree Select
Feedback
ON/OFF
Movement Feedback
Move. Speed
Speed 1 ~ 4
Movement Mode Select
Dormancy
OFF, 01M~99M, 15M
Stand By Mode
Fixtrure ID
Service PIN
PIN= 050
Enter PIN to Access Fixture ID Menus
Universe
0-255
Set DMX Universe (PSWD Required)
UnitIPAddr
XXX . XXX . XXX . XXX
Set Ethernet IP (PSWD Required)
Mask ADDR
XXX . XXX . XXX . XXX
Set Ethernet Mask IP (PSWD Required)
Protocol Set
ArtNet, sACN
Select Ethernet Protocol
KlingNet
Enable, Disable
Select KlingNet Protocol
Net Switch
ON, OFF
Enable Net Switch Function
Dim Mode
Standard, Stage, TV, Architectur, Theatre
Set Dimmer Curve Mode
Temp. C/F
Celsius/Fahrenheit
,:BE:G6IJG:+L>I8=:IL::CZZ
Gamma
2.0, 2.2, 2.4, 2.8
Set Gamma Brightness
Frequency
900Hz, 1000Hz, 1100Hz, 1200Hz, 1300Hz,
1400Hz, 1500Hz, 2500Hz, 4000Hz, 5000Hz,
10Hz, 15Hz, 20Hz, 25Hz
Set LED Refreash Frequency
E-FLY
OFF, ON
Enable E-FLY Wireless DMX
Wireless
CH:00, 01-14
Set E-FLY Wireless Channel
Fan Set
Head Fan
Auto, High, Low
Set Head Fan Speed
LCD. Set
Backlight
02~60m 05m
LCD Backlight Shut Off Time
FlipDisplay
ON / OFF
Flip/Reverse LCD Display 180º
Key Lock
ON / OFF
Control Front Panel Buttons Key Lock
Disp Flash
ON / OFF
Display flashes when NO DMX
Disp. Set
Chan. Value
ALL ~ Dim Modes
Value of each Channel Displayed
Slave Set
Slave 1, Slave 2, Slave 3
Set Slave Mode Preset
Auto.Pro
Alone, Master
Set Auto Program Mode
DFSE
OFF, ON
Restore Factory Settings
USB Update
OFF, ON
N/A - FUTURE OPTION TBA
