ELATION© DARTZ 360™
S Y S T E M M E N U
Features are subject to change without any prior written notice.
Supports Software Versions: ≥ 1.1.5
MAIN MENU
SUB MENU
OPTIONS / VALUES (Default Settings in BOLD)
DESCRIPTION
Information
Time. Info
CurrentTime
XXXX (Hours)
Fixture Run Time From Power ON
Total Time
XXXX (Hours)
Fixture Total Run Time
Last Time
XXXX (Hours)
Clear Fixture Last Run Time
Timer PIN
PIN= 050
Enter PIN to Access Clear Last. Menu
Clear Last
ON / OFF
Reset Fixture Last Run Time
Temp. Info
R:xxxF°
Temperature of RED LED
G:xxxF°
Temperature of GREEN LED
B:xxxF°
Temperature of BLUE LED
Fan Speed
Fan1 :xxxx RPM
Speed of Fan1
Fan2 :xxxx RPM
Speed of Fan2
Error. Info
Error Record 1 ~ Error Record 10
Display 10 Recent Error Messages
Model. Info
DARTZ 360
Display Model Name
Software.V
1U01:
V0.0.0
Software Versions
(Greater than or Equal to)
2U01:
V0.0.0
3U01:
V0.0.0
4U01:
V0.0.0
5U01:
V0.0.0
Test
Reset. Motor
All, Pan&Tilt, Fixed Gobo
Reset of Motors
TestChannel
Pan, Pan Fine, Tilt, Tilt Fine, Pan Rotate, Tilt Rotate,
Red, Red Fine, Green, Green Fine, Blue, Blue Fine,
Fixed Gobo, Prism1, Prism1Rot, Prism2, Prism2Rot,
Strobe, Dimmer, Dim Fine, Focus, Frost, DimMode,
P/T Speed, Reset/Prog
Test Functions
Panel. Ctrl
Pan,Tilt, Pan Rotate, Tilt Rotate, Red, Green, Blue,
Fixed Gobo, Prism1, Prism1Rot, Prism2, Prism2Rot,
Strobe, Dimmer, Dim Fine, Focus, Frost, DimMode,
P/T Speed, Reset/Prog
Fine Adjustments
Calibrate
Password
Password= 050
Calibration of Motors and LEDs
Program
Select. Pro
Auto Pro Part1 = Program 1~9 (Program 1)
Select Programs To Be Run
Auto Pro Part2 = Program 1~9 (Program 2)
Auto Pro Part3 = Program 1~9 (Program 3)
Edit. Pro
Program 1
Program Test
Testing Program
:
Step 01=SCxxx
Program In Loop
Program 9
Step 64=SCxxx
Save and Exit
Edit. Sce
Scene 001
~
Scene 250
Pan,Tilt,……
Save and Automatically Return
--Fade Time--
--Scene Time--
Manual Scenes Edit
Input By Outside
Stores Scenes via Ext DMX Console
