www.elationlighting.com 20
DMX CHANNEL FUNCTIONS AND VALUES
ELATION© DARTZ 360™
DMX Channel Values / Functions (25 DMX Channels)
Supports Software Versions: ≥ 1.1.5
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
1 1 1
PAN MOVEMENT [8 BIT]
000-255
PAN Movement
2 2
PAN FINE MOVEMENT [16 BIT]
000-255
Fine Control of PAN Movement
2 3 3
TILT MOVEMENT [8 BIT]
000-255
TILT Movement
4 4
TILT MOVEMENT [16 BIT]
000-255
Fine Control of TILT Movement
3 5 5
PAN CONTINUOUS MOVEMENT
000-127
NO FUNCTION
128-189
PAN Clockwise from FAST to SLOW
190-193
NO Rotation
194-255
PAN Counter-Clockwise from SLOW to FAST
4 6 6
TILT CONTINUOUS MOVEMENT
000-127
NO FUNCTION
128-189
TILT Clockwise from FAST to SLOW
190-193
NO Rotation
194-255
TILT Counter-Clockwise from SLOW to FAST
5 7 7
RED
000-255
Red (0-Black - 255-100%)
8
RED FINE
000-255
Red FINE Adjustment
6 8 9
GREEN
000-255
Green (0-Black - 255-100%)
10
GREEN FINE
000-255
Green FINE Adjustment
7 9 11
BLUE
000-255
Blue (0-Black - 255-100%)
12
BLUE FINE
000-255
Blue FINE Adjustment
