ELATION© DARTZ 360™
DMX Channel Values / Functions (25 DMX Channels)
Supports Software Versions: ≥ 1.1.5
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
8 10 13
FIXED GOBOS
000-003
OPEN
004-007
Fixed Gobo 01
008-011
Fixed Gobo 02
012-015
Fixed Gobo 03
016-019
Fixed Gobo 04
020-023
Fixed Gobo 05
024-027
Fixed Gobo 06
028-031
Fixed Gobo 07
032-035
Fixed Gobo 08
036-039
Fixed Gobo 09
040-043
Fixed Gobo 10
044-047
Fixed Gobo 11
048-051
Fixed Gobo 12
052-055
Fixed Gobo 13
056-059
Fixed Gobo 14
060-063
OPEN
064-073
Fixed Gobo 01 Shake SLOW to FAST
074-083
Fixed Gobo 02 Shake SLOW to FAST
084-093
Fixed Gobo 03 Shake SLOW to FAST
094-103
Fixed Gobo 04 Shake SLOW to FAST
104-113
Fixed Gobo 05 Shake SLOW to FAST
114-123
Fixed Gobo 06 Shake SLOW to FAST
124-133
Fixed Gobo 07 Shake SLOW to FAST
134-143
Fixed Gobo 08 Shake SLOW to FAST
144-153
Fixed Gobo 09 Shake SLOW to FAST
154-163
Fixed Gobo 10 Shake SLOW to FAST
164-173
Fixed Gobo 11 Shake SLOW to FAST
174-183
Fixed Gobo 12 Shake SLOW to FAST
184-193
Fixed Gobo 13 Shake SLOW to FAST
194-203
Fixed Gobo 14 Shake SLOW to FAST
204-211
NO FUNCTION
212-232
Gobo Wheel Rotation CLOCKWISE SLOW to FAST
233-234
NO Rotation
235-255
Gobo Wheel Rotation COUNTER-CLOCKWISE SLOW to FAST
9 11 14
8-FACET PRISM 1
000-031
OPEN
032-255
8-FACET PRISM 1
10 12 15
8-FACET PRISM 1 ROTATION
000-127
Index Rotation
128-189
CLOCKWISE Rotation FAST to SLOW
190-193
NO Rotation
194-255
COUNTER-CLOCKWISE Rotation SLOW to FAST
