www.elationlighting.com 22
ELATION© DARTZ 360™
DMX Channel Values / Functions (25 DMX Channels)
Supports Software Versions: ≥ 1.1.5
Features are subject to change without any prior written notice.
*Rotation direction (Clockwise or Counterclockwise) of effects depends on orientation of the fixture head and Pan/Tilt settings.
MODE / CHANNEL
VALUE FUNCTION
BASIC
STAND
EXTEND
11 13 16
6-FACET PRISM 2
000-031
OPEN
032-255
6-FACET PRISM 2
12 14 17
6-FACET PRISM 2 ROTATION
000-127
Index Rotation
128-189
CLOCKWISE Rotation FAST to SLOW
190-193
NO Rotation
194-255
COUNTER-CLOCKWISE Rotation SLOW to FAST
13 15 18
SHUTTER, STROBE
000-031
LEDs OFF
032-063
LEDs ON
064-095
Strobe Effect SLOW to FAST
096-127
LEDs ON
128-159
Pulse Effect In Sequences
160-191
LEDs ON
192-223
Random Strobe Effect SLOW to FAST
224-255
LEDs ON
14 16 19
DIMMER INTENSITY
000-255
Dimmer 0 to 100%
17 20
DIMMER INTENSITY FINE
000-255
Dimmer FINE Adjustment
15 18 21
FOCUS
000-255
Continuous Adjustment from FAR to NEAR
16 19 22
FROST
000-225
0-100% Linear Frost
226-235
Pulse Opening Effect from FAST to SLOW
236-245
Pulse Closing Effect from SLOW to FAST
246-255
100% Frost
17 20 23
DIMMER MODES
000-020
Standard
201-040
Stage
041-060
TV
061-080
Architectural
081-100
Theatre
101-255
Default to Setting on Fixture
18 21 24
PAN / TILT MOVEMENT SPEED
000-225
MAX to MIN Speed
226-235
Blackout by Movement
236-245
NO FUNCTION
246-255
NO FUNCTION
