Elation DP-DMX20L - Table of Contents

Power Input ...................................................... AC 120V~50-60Hz, 20 A max.
Channel Output ........................................... 10A per channel, Total 20 A max.
DMX OUT ........................................................................... 3-pin XLR female
DMX IN .................................................................................. 3-pin XLR male
External load fuse............................................................. F10A 250V 5x20mm
Dimensions ..........................................8.35L x 7.4W x 2.8H (212x188x71mm)
Weight ......................................................................................5.29lbs.(2.4 Kg)
Internal main fuse........................................................ F0.315A 250V 5x20mm
Technical Specifications
11
Table of Contents
General Instruction..........................................................................2
Warnings.........................................................................................2
Cautions......................................................................................... 2
Features ...........................................................................................1
Control and Functionss .................................................................. 3
Front Panel Layout ..................................................................3 & 4
Rear Panel Layout......................................................................... 4
Operation Guide.............................................................................. 5
Menu Options................................................................................. 5
Chase Mode..................................... ............................5 & 6
Receive (DMX) Mode................ ..............................7 & 8
............
.................
Installation Mounting & Connections.
Troubleshooting
, ......................................... 9
Installation / Mounting................................................................... 9
Connections...................................................................................9
............................................................................10
Troubleshooting........................................................................... 10
Fuse Replacement.......................................................................10
Technical Specifications...............................................................11
