38
Fig. 2.33
1
2
Fig. 2.34
Fig. 2.32
3. Remove the middle pane:
• Gently unlock the middle pane of glass
from the bottom clamps by moving it
as in g. 2.33.
• Gently lift the bottom edge of the pane
(arrow 1 in g. 2.34) and remove it
by pulling it out from the top clamps
(arrow 2 in g. 2.34).
• Clean the glass with an appropriate
cleaner. Dry thoroughly, and place on
a soft surface.
Now you can also clean the inside of the
outer glass.
