ELCA E1 - 7.3 ENABLING IDENTIFICATION CODE CARD

ENG man E1-MIA 00 E1-MIA Radio Remote Control
- Page 17 -
ENGLISH
Any equipment replacing the card with the identi cation code must be enabled for its use by the identi cation code
acquisition procedure.
At the  rst power on the transmitter, the red and green LEDs are lit up for 3 seconds at the same time, and then it remains
awaiting command inputs with the green  ashing light  ashing slowly.
7.3 ENABLING IDENTIFICATION CODE CARD
START
At the  rst press of the START key, the red
and green LEDs light up for 3 seconds.
Enter the PIN CODE.
The default PIN CODE is the sequence of
START, K0, START keys.
The green LED lights up for 1 second and
then turns off.
Then the Green LED blinking slowly.
Press Start and then enter the PIN CODE.
The transmitter is now on.
K7
STARTSTART
K7
STARTSTART
START
