SoilTest PRO Auto Soils Consolidator (ASC)
25-0500
Original Instructions 28 9901X0275 Issue 2
Appendix 3: Troubleshooting Guide
No display showing No power Check power supply and fuses
Screen brightness set too
low
Adjust brightness
Internal cables loose Refer to ELE Customer Service
Machine not operating Frame travel on limit Check cross-head set up
LVDT sensor over-range Check sensor position
Load cell over-range Check frame
Machine not reaching
START position
Frame cross head too low
Move the cross head up, level and
secure
Test stopping due to
LVDT overload
LVDT not adjusted
correctly
Move LVDT up
