<FIXED>, <TRACK>, <SLIDE> (etc.): This function controls how the
panadapter display moves with respect to the VFO cursor. The
different modes are described below.
<FREEZE>: Suspends the panadapter spectrum and waterfall. This is
useful in conjunction with screen capture to a file on a flash drive
(see Fn).
<CURS A> & <CURS B>: Turns VFO cursors on (+) or off (-). The default
is on for each, but you may wish to turn a cursor off when not needed.
Panadapter Cursor Modes
The following cursor position modes are available. These are accessed
by tapping the panadapter secondary function button that is second
from the right.
NOTE: If either or both VFO cursors falls outside the screen, triangular
icons will appear to show whether they are off-screen to the left or
right. The VFO A icon is blue, VFO B green.
• TRACK: The panadapter frequency range is continually adjusted to
keep it centered on the VFO cursor frequency. (In all other modes, the
cursor moves, and the panadapter stays in a fixed position until it
approaches an edge.)
• FIXED1: When the cursor hits either edge, the panadapter is shifted
in that direction by an amount equal to its full frequency range.
• FIXED2: Same as FIXED1, except the shift is half the range.
• SLIDE1: When the cursor hits either edge, the panadapter window is
shifted smoothly as the cursor continues to move in that direction.
• SLIDE2: Same as SLIDE1, except that shifting begins before the
cursor reaches the edge.
• STATIC: Panadapter position never shifts (cursor will disappear at
the edges).
