Electra Delta 22 - Electrical Data

7-1
ELECTRICAL DATA
Revision Y05-02Service Manual - Delta DCI
7. ELECTRICAL DATA
7.1 Single Phase Units
MODEL Delta 22 Delta 25
Power Supply
To indoor To indoor
1PH,220-240V,50Hz 1PH,220-240V,50Hz
Max Current, A 5.2 6.3
Circuit Breaker,A 12 12
Power Supply
Wiring No. X Cross Section mm
2
3x1.0 mm
2
3x1.0 mm
2
Interconnecting Cable RCModel
Wiring No. X Cross Section mm
2
4x1.0 mm
2
4x1.0 mm
2
MODEL Delta 50 Delta 35
Power Supply
To indoor To indoor
1PH,220-240V,50Hz 1PH,220-240V,50Hz
Max Current, A 10.3 7.5
Circuit Breaker,A 20 15
Power Supply
Wiring No. X Cross Section mm
2
3x1.5 mm
2
3x1.5 mm
2
Interconnecting Cable RC Model
No. X Cross Section mm
2
4x1.5 mm
2
5x1.5 mm
2
(a) The Inrush current is the current when power is up (charging the DC capacitors of
the outdoor unit controller).
(b) Starting current is the current when starting the compressor.
NOTE
Power wiring cord should comply with local lows and electrical regulations
requirements.
