Electra Delta 22 - Outline Dimensions

4-1
OUTLINE DIMENSIONS
Revision Y05-01Service Manual - Delta DCI
4. OUTLINE DIMENSIONS
4.1 Indoor Unit: Delta 22, 25 DCI
4.2
Indoor Unit: Delta 35 DCI
185
250
680
AIR OUTLET
AIR INTAKE
AIR INTAKE
INDOOR UNIT OUTLINE
244
160
118
TUBING WALL OPENING
(FOR REAR LEFT ROUTING)
670
41
40
TUBING WALL OPENING
(FOR REAR ROUTING)
380
52
80
141
MOUNTING TEMPLATE
TO BE USED FOR LOCATION
OF INDOOR UNIT ON THE WALL
58
Min50
306
46
CEILING
185
250
840
AIR OUTLET
AIR INTAKE
830
160
AIR INTAKE
TUBING WALL OPENING
(FOR REAR ROUTING)
TUBING WALL OPENING
(FOR REAR LEFT ROUTING)
504
137
50
40
52
MOUNTING TEMPLATE
TO BE USED FOR LOCATION
OF INDOOR UNIT ON THE WALL
CEILING
406
172
70
59
Min50
244
80
INDOOR UNIT OUTLINE
