Electra Delta 22 - Page 68

13-2
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-02 Service Manual - Delta DCI
13.2 Indoor Unit: Delta 22, 25 DCI
No. Part No. Name Quan. Version
1
453037000
Grill A / DELTA 22,25 1 1
2
453100500
Grill L axis 1 1
3
453100600 Grill R axis
1 1
4
453036500
Filter for DELTA 7/9 2 1
7
465720000
Silk-screen front frame for Electra 1 1
8
4525987
SCREW COVER 3 1
9
453070701
Evap. System Assy./DELTA 22,25 1 1
10
4523526
BERAING ASSY FAN 1 1
11
4523523
FAN ASSY PLASTIC 1 1
12
452784400
IOD-7,9 Air Outlet Assy. (no wire) 1 1
13
4523693
DRAIN HOSE 1 3
14
4526659
REAR PANEL ASSY 1 1
15
453027400
Mount Bracket Assy./Alfa 7,9 1 1
16
4526000
TUBE CLIP 1 1
17
453130700
Remote Controller RC-7 Silver )EHK P/N 977-800-40 1 1
18
4526133
Power cord cable 1 1
19
4523507
Step motor 1 2
20
453089600
Display assy. for DELTA EHK:936-034-00 1 1
21
453088600
PG Resin motor 12W 1 2
22
453089500
DELTA DCI indoor controller EHK: 916-540-00 1 1
23
4525998
MOTEOR COVER 1 1
24
438082
Thermistor Indoor coil BLACK 1 1
25
4519813
Thermistor room 1 2
26
453027000
Terminal Cover 1 2
