Electra evolution - Supply Control Unit Features; Video Connection Box Features; Access Tag Features

04
2.3 Technical features of the Supply control unit
Supply tension
+14V - GND : +14V DC (stabilized)/ 2A DC
+ Uv GND : +14V DC -
Vcam
GND : +12V DC -
(stabilized)/ 0.5A DC
(stabilized) / 0.4A DC
Generated power tensions/
power capability
Case
Mounting
Fireproof ABS
- On DIN rail: TH 35 x 15 or 35 x 7,5 in compliance
with DIN46277-3, EN50022, IEC60715
- Surface: with A3,5 x 32 plastic screws and
ø 6 mm pins
Casing protection level
Operating temperature range
IP31
0°C ... + 45°C
Transport and storage
temperature range
Dimensions
Weight
- 33°C ... + 55°C
130 x 141 x 73 mm
0,4 kg
230V±10%/50Hz
Outputs (derivations)
-On DIN rail: TH 35 x 15 or 35 x 7,5 in compliance
with DIN46277-3, EN50022, IEC60715
-Surface: with plastic screws and pins
2
Case
ABS
Mounting
0,21 kg
100 x 71 x 60 mm
Casing protection level (IP)
IP31
Operating temperature range
0° C ... + 45° C
Range of transport and storage
temperatures
- 33° C ... + 55° C
Dimensions
Weight
Main input – output
1
2.5 Technical features of the Video connection box
Functioning frequency
125kHz
2.5 Technical features of the Access tag
