4.1 Recommended cables
Outdoor panel Supply control unit
UTP CAT5e (AWG24) cable for distances of maximum 70 m between the outdoor panel and
the supply control unit and 250m between the outdoor panel and the video terminal.
For distances greater than 250 m, please request additional information from the producer.
Video terminalVideo connection box
06
To the video
Terminal
/
6
/
6
Panel
Supply control unit
/
4
/
4
/
4
/
4
/
6
Video selection box
3.2 Block diagram of the connection of additional Outdoor
panels (optional)
INSTALLATION4
To the video Terminal
Video selection box
Panel 1 Panel 2 Panel 3 Panel 4
/
6
Supply
control
unit 3
Supply
control
unit 2
Supply
control
unit 4
Supply
control
unit 1
/
6
/
6
/
6
/
6
/
6
/
6
/
6
/
6
3.1 Block diagram of the video selection box connected with
4 additional video cameras (optional)
