Why is my Electra GC 24 RC not cooling or heating, and only the indoor fan is working?
If your Electra Air Conditioner isn't cooling or heating, and only the indoor fan is working, the outdoor fan motor may be faulty, or another issue may have caused the compressor overload protection to activate. Try removing any obstructions blocking the outdoor fan. If that doesn't work, the P.C.B. may need replacement.
Why is my Electra GC 24 RC Air Conditioner blowing air but not cooling or heating?
If your Electra Air Conditioner is not cooling or heating, but the indoor fans are working, it could be due to the overload safety device on the compressor being cut out because of low voltage or high temperature. Check for proper voltage. Switch off the power and try again after one hour. If the problem persists, consider replacing the compressor capacitor or the compressor itself.
How to troubleshoot an Electra GC 24 RC Air Conditioner when the outdoor fan is not working?
If your Electra Air Conditioner's outdoor fan isn't functioning correctly, check the voltage between the outdoor fan terminals on the main P.C.B. If there's no voltage, replace the main P.C.B. If there is voltage, replace the capacitor or motor. You should also check and repair the electrical wiring between the indoor and outdoor units.
How to fix Electra GC 24 RC when the indoor fan is not working correctly?
If the indoor fan in your Electra Air Conditioner isn't working correctly, check the voltage between the indoor fan terminals on the main P.C.B. If there is voltage, replace the capacitor or motor.
What to do if the Electra GC 24 RC Air Conditioner compressor does not start up?
If your Electra Air Conditioner compressor isn't starting, begin by checking the voltage on the compressor terminals on the outdoor unit. If there's no voltage, repair the electrical wiring between the indoor and outdoor units. If the voltage is low, repair the power supply. If the voltage is correct, replace the capacitor or the compressor.
Why is my Electra Air Conditioner in heat mode but operating in cooling?
If your Electra Air Conditioner is in heat mode but operating in cooling, the RV coil may be faulty, so replace the RV coil. If the RV coil is okay, the valve may be stuck in position, so replace the reversing valve.
Why is only the indoor fan and compressor working on my Electra GC 24 RC?
If your Electra Air Conditioner only has the indoor fan and compressor working, it's likely that the outdoor fan is blocked. Remove any obstructions to allow it to function correctly.
Why is there no air supply from the indoor unit of my Electra Air Conditioner, even though the compressor is running?
If your Electra Air Conditioner's indoor fan isn't providing enough air, and the compressor is running, the indoor fan motor might be blocked or turning slowly. Check the voltage and repair the wiring if necessary. Also, check if the fan wheel is tight enough on the motor shaft and tighten it if necessary.
Why is only the indoor fan working on my Electra GC 24 RC Air Conditioner?
If your Electra Air Conditioner is only running the indoor fan, the run capacitor of the outdoor fan motor may be faulty, so replace the capacitor. Alternatively, the windings of the outdoor fan may be shorted, so replace the motor.
Why is the operation indicator on my Electra GC 24 RC Air Conditioner not lighting up?
If the operation indicator (green LED) on the central control display panel of your Electra Air Conditioner does not light up, the remote control batteries are discharged. Replace the batteries of the remote control.
General| Brand | Electra |
|---|---|
| Model | GC 24 RC |
| Category | Air Conditioner |
| Language | English |
Details the DELTA split wall mounted models (ST and RC) and their features.
Lists key technological innovations of the DELTA series, like R410A refrigerant and microprocessor control.
Describes the wall-mounted indoor unit and its included components.
Outlines the different types of air filters available for the DELTA series.
Mentions the microprocessor controller and infrared remote control for operation and programming.
Details the installation, features, and components of the DELTA outdoor units.
Lists optional accessories like ASK and RCW, and mentions inbox documentation.
Presents a table showing compatible indoor and outdoor units for R410A refrigerant.
Provides detailed specifications for the DELTA 18 indoor unit and GC 18 outdoor unit with R410A.
Lists specifications for the DELTA 21 indoor unit and GC 22 outdoor unit with R410A.
Details specifications for the DELTA 24 indoor unit and OU7-24 outdoor unit with R410A.
Provides specifications for the DELTA 24 indoor unit and OU7-24Z outdoor unit with R410A.
Lists specifications for the DELTA 24 indoor unit and OU7-24T outdoor unit with R410A.
Defines the operating limits for cooling and heating modes, including voltage specifications.
Shows dimensional drawings and measurements for the DELTA 18, 21, 24 indoor units.
Presents dimensional drawings and measurements for the GC 18 and GC 22 outdoor units.
Displays dimensional drawings and measurements for the OU7-24 and OU7-24Z outdoor units.
Provides cooling performance data for DELTA 18/GC 18 at 7.5m tubing, with legend.
Offers heating performance data for DELTA 18/GC 18 at 7.5m tubing, with legend.
Details correction factors for cooling and heating based on tubing length.
Shows suction and discharge pressure graphs vs. outdoor temperature for cooling.
Displays suction and discharge pressure graphs vs. outdoor temperature for heating.
Provides cooling performance data for DELTA 21/GC 21 at 7.5m tubing, with legend.
Offers heating performance data for DELTA 21/GC 21 at 7.5m tubing, with legend.
Shows suction and discharge pressure graphs vs. outdoor temperature for cooling.
Displays suction and discharge pressure graphs vs. outdoor temperature for heating.
Provides cooling performance data for DELTA 24/OU7-24 at 7.5m tubing, with legend.
Offers heating performance data for DELTA 24/OU7-24 at 7.5m tubing, with legend.
Shows suction and discharge pressure graphs vs. outdoor temperature for cooling.
Displays suction and discharge pressure graphs vs. outdoor temperature for heating.
Describes how sound pressure level is measured, including a diagram.
Presents octave band sound pressure level spectra for DELTA indoor units.
Shows octave band sound pressure level spectra for GC 18/22 outdoor units.
Displays octave band sound pressure level spectra for OU7-24Z/OU7-24 outdoor units.
Details power supply, current, circuit breaker, and wiring for single-phase units.
Shows the wiring diagram for DELTA 18, 21, and 24 indoor units.
Presents the wiring diagram for the GC 18 1PH outdoor unit (Heat Pump Model).
Shows the wiring diagram for the GC 24 1PH outdoor unit (Heat Pump Model).
Displays the wiring diagram for the OU7-24 1PH outdoor unit.
Presents the wiring diagram for the OU7-24 3PH outdoor unit.
Shows the wiring diagram for the OU7-24Z outdoor unit.
Illustrates electrical connections for DELTA 18/21 1PH indoor and outdoor units.
Shows electrical connections for DELTA 24 1PH indoor and outdoor units.
Displays refrigeration diagrams for DELTA 18 in cooling and heating modes.
Shows refrigeration diagrams for DELTA 24/OU7-24 in cooling and heating modes.
Displays refrigeration diagrams for DELTA 24/OU7-24Z in cooling and heating modes.
Presents refrigeration diagrams for DELTA 18, 21, 24 cooling-only models.
Introduces electronic control for service applications and lists model groups.
Identifies components on the main PCB controller and the LED display.
Explains general functions, protections, and thermistor faults.
Details cooling mode general functions, control functions, and cooling with autofan.
Covers heating mode general, IF rules, HE operation, and RC/SH group controls.
Describes automatic cooling/heating general functions and RC/SH group controls.
Explains dry mode control function, COMP/IFAN operation, and notes.
Details protections like defrost, high pressure, and deicing for various modes.
Details how the timer starts/stops operation, settings, and power failure effects.
Explains how forced operation allows starting/stopping at pre-set temperatures.
Describes sleep mode activation, SPT adjustment, and time adjustment.
Describes the filter LED indicator and how to reset the filter timer.
Outlines the self-test flow chart by jumper or remote control settings.
Explains indicator functions and control buttons on the unit.
Explains clock activation, interruption, and reset.
Details how to activate diagnostic mode and how problems are indicated by LEDs.
Exploded view diagram for DELTA 18, 21, 24 indoor units.
Parts list for DELTA 18, 21, 24 indoor units.
Exploded view diagram for GC 18 ST outdoor unit.
Parts list for GC 18 ST outdoor unit.
Exploded view diagram for GC 18 RC outdoor unit.
Parts list for GC 18 RC outdoor unit.
Exploded view diagram for GC 21 RC outdoor unit.
Parts list for GC 21 RC outdoor unit.
Exploded view diagram for GC 21 ST outdoor unit.
Parts list for GC 21 ST outdoor unit.
Exploded view diagram for GCN 12 RC outdoor unit.
Parts list for GC 24 ST outdoor unit.
Exploded view diagram for GC 24 RC outdoor unit.
Parts list for GC 24 RC outdoor unit.
Exploded view diagram for OU7-24 RC 1PH outdoor unit.
Parts list for OU7-24 RC 1PH outdoor unit.
Exploded view diagram for OU7-24 ST 1PH outdoor unit.
Parts list for OU7-24 ST 1PH outdoor unit.
Exploded view diagram for OU7-24Z RC/ST 1PH outdoor unit.
Parts list for OU7-24Z RC/ST 1PH outdoor unit.
Exploded view diagram for OU7-24 RC 3PH outdoor unit.
Parts list for OU7-24 RC 3PH outdoor unit.
Exploded view diagram for OU7-24 ST 3PH outdoor unit.
Parts list for OU7-24 ST 3PH outdoor unit.
Describes the RCW wall-mounted remote control, its features, and ordering code.
Details the RCW2 wired controller, its capabilities, and ordering code.
Explains the ASK as a pressure regulator for low-temperature cooling.
Refers to the separate installation and operation manual for DELTA 18, 21, 24 models.
