EXPLODED VIEWS & SPARE PARTS LISTS
13-8 SM PXD 1-E.3 GB
13.8 Indoor Unit: PXD 30
No. Item Code Item Desc Quantity
13 221554 FILTER PXD (BIG) 2
25 234213 DISPLAY BOX PXD EHK: 906-041-02 1
22 263034 SWING MOTOR 1
7 293322 CENTRIFUGAL FAN (BIG) 2
1 307980 BACK PANEL £¨BIG£© 1
14 307982 FRONT PANEL (BIG) 1
30 311036 STORM METAL PANEL 1
6 323422 MOTOR SUPPORT LENGTH 132 1
18 370280 AIR OUTLET FRAME (BIG) 1
17 371257 VERTICAL LOUVER CONNECTOR 12
20 372336 HORIZONTAL LOUVER FRONT (BIG) 1
21 372337 HORIZONTAL LOUVER BACK (BIG) 1
11 372340 FAN COVER (BIG) 2
16 373244 RIGHT PANEL 1
12 373245 Side Plate / Left 1
4 373246 FAN FRAME (BIG) 1
19 375209-16 DISPLAY PANEL ASSY.---ELECTRA 1
2 382333 BASE EPS (BIG) 1
24 391508 CABLE DISPLAY 1
26 391726 Power Supply 1
23 436665 STEP MOTOR 1
27 438082 Thermistor Indoor 1
28 438413 ROOM Sensor 1
10 4520429 MOTOR WIRE ---PXD 1
8 4520932 Motor Assy. for PXD32 1
9 4521029 CLIP 2
29 452837700 STORM-1 (PXD & K)916-355-18 1
None 452837700 STORM-1 (PXD & K)916-355-18 1
None 452837700R STORM-1 (PXD & K)916A355-18 1
3 453154800 Evaporator Assy. 1
5 455000602 Capacitor With Screw for fan motor 1
15 484002 AIR INLET ASSY (BIG) 1
