PERFORMANCE DATA & PRESSURE CURVES
5-1SM PXD 1-E.3 GB
5. PERFORMANCE DATA
5.1 PXD9 ONG9 R410A
5.1.1 Cooling Mode at 7.5m Tubing Connection.
230V : Indoor Fan at High Speed.
ENTERING AIR
DB OU COIL (°C)
DATA
ENTERING AIR WB/DB ID COIL ( °C)
15/21 17/24 19/27 21/29 23/32
15
(1)
TC
2.80 2.90 2.97 3.04 3.09
SC
1.85 1.93 2.01 2.06 2.09
PI
0.59 0.59 0.59 0.59 0.60
20
(1)
TC
2.71 2.86 2.95 3.02 3.08
SC
1.81 1.91 1.99 2.05 2.09
PI
0.64 0.64 0.64 0.65 0.65
25
TC
2.57 2.77 2.91 3.00 3.07
SC
1.77 1.88 1.98 2.03 2.07
PI
0.69 0.70 0.70 0.70 0.71
30
TC
2.40 2.61 2.82 2.92 3.01
SC
1.71 1.82 1.93 1.99 2.03
PI
0.74 0.76
0.76
0.77 0.78
35
TC
2.22 2.41
2.66
2.79 2.93
SC
1.63 1.75 1.89 1.94 1.98
PI
0.80 0.82
0.83
0.84 0.84
40
TC
2.02 2.20
2.40
2.62 2.76
SC
1.53 1.65 1.79 1.84 1.88
PI
0.87 0.88 0.89 0.91 0.91
46
TC
1.75 1.92 2.11 2.33 2.51
SC
1.41 1.51 1.63 1.69 1.72
PI
0.95 0.96 0.98 1.00 1.01
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
(1) Marked area is below standard operating limits. For operating in low ambient
conditions, refer to Optional Accessories (Chapter 15).
