EXPLODED VIEWS & SPARE PARTS LISTS
13-11SM PXD 1-E.3 GB
13.11 Outdoor Unit: ONG 12 ST
Item Code Item Desc Quantity
Drawing
Number Effective From Effective To
433218 Front Panel A 1 1 15-Nov-03 13-Jan-04
433219 Front Panel A1 1 1 13-Jan-04 Active
433221 Air Inlet Ring-420 1 2 15-Nov-03 Active
433223 Painting Insulation Plate 1 3 15-Nov-03 Active
4519251 Axial Fan OD=400 1 4 15-Nov-03 Active
4519692 Fan Motor (810rpm) 1 5 15-Nov-03 Active
433215 Motor Support 1 6 15-Nov-03 16-Feb-04
4527203 Motor Support 1 6 16-Feb-04 Active
4519601 Base Painting Assy. 1 7 15-Nov-03 15-Nov-03
4526747 Base Painting Assy. 1 7 15-Nov-03 16-Feb-04
452772500 Base Plate Painting Assy. 1 7 16-Feb-04 Active
433217 Partition Plate 1 8 15-Nov-03 Active
4517993 Cap. 35uF/450V 1 9 15-Nov-03 29-Dec-03
455000504 Compressor Capacitor With Screw 1 9 29-Dec-03 Active
4519611 Electric Panel Painting Plate 1 10 15-Nov-03 Active
4524176 1/4 Liqiud Valve(R410A) 1 11 15-Nov-03 Active
4524595 1/2 Gas Valve for ONG R410A 1 12 15-Nov-03 13-Jan-04
4524177 3/8 Gas Valve(R410A) 1 12 13-Jan-04 Active
4517990 Cap. 2uF/450V 1 13 15-Nov-03 08-Jan-04
455000001 single patch Capacitor for fan 1 130 08-Jan-04 09-Feb-04
455000108 Double patch Capacitor for fan 1 13 09-Feb-04 Active
4514588 5 Poles terminal block 1 14 15-Nov-03 Active
204107 Cable clip Nylon 1 15 15-Nov-03 Active
236179 2 Poles terminal block 1 16 15-Nov-03 16-Feb-04
4516637 Out sensor Black 1 17 15-Nov-03 16-Feb-04
4525210 Restrictor (031) 1 18 15-Nov-03 13-Jan-04
4524923 Capillary 2.6*1.6*800 1 19 15-Nov-03 13-Jan-04
4526848 Capillary Assy. (OD2.6xID1.6x1000) 1 19 13-Jan-04 Active
4525650 Charge tube 1 20 15-Nov-03 13-Jan-04
4527362 Charge tube TP2 ¦?6.35x0.8 1 20 13-Jan-04 Active
4519600 Compresssor Jacket 1 21 15-Nov-03 13-Jan-04
4527007 Comp. Jacket 1 21 13-Jan-04 16-Feb-04
4527058 Comp. Jacket 1 21 16-Feb-04 Active
4519610 Compressor Isolation. Top Cover 1 22 15-Nov-03 13-Jan-04
4514091 Grommet 3 23 15-Nov-03 15-Nov-03
4516357 Rubber Cushion 1K15910311 3 23 15-Nov-03 Active
4510677 Nut With Flange M8 -D=24 3 24 15-Nov-03 Active
4519987 Wire assy 1 25 15-Nov-03 13-Jan-04
4527008 Wire assy 1 25 13-Jan-04 16-Feb-04
4519987 Wire assy 1 25 16-Feb-04 Active
4524232 Compressor assy. GK151PAD 1 26 15-Nov-03 15-Nov-03
4526452 Comp. Assy GMCC PA145X2C-4FT 1 26 15-Nov-03 Active
4516359 Terminal Packing 1K14720130 1 27 15-Nov-03 Active
4516826 Rubber washer 1 27 15-Nov-03 15-Nov-03
4516358 Terminal Cover 1K14720012 1 28 15-Nov-03 Active
4516825 Cover Terminal 1 28 15-Nov-03 15-Nov-03
4514089 Nut hex 1 29 15-Nov-03 15-Nov-03
4516360 Terminal Nut 1K14300710 1 29 15-Nov-03 Active
433229 Valve Cover 1 30 15-Nov-03 Active
433234 Clamp 1 31 15-Nov-03 Active
4518950 Filter Drier BFK-053S 1 31 15-Nov-03 13-Jan-04
4519606 Right side panel (painting plate) 1 32 15-Nov-03 Active
4526790 Discharge Tube Assy. 1 33 15-Nov-03 Active
4525081 Suction Tube 12.7*0.8*1090 1 42 15-Nov-03 15-Nov-03
4526791 Suction Tube Assy 1 34 15-Nov-03 Active
433228 Back Side Net 1 35 15-Nov-03 Active
433216 Bridge 1 36 15-Nov-03 Active
433235 SPACER A 22*1 1 37 15-Nov-03 16-Feb-04
4525529 condensor Soldering assy 1 47 15-Nov-03 13-Jan-04
4526806 condensor Soldering assy 1 38 13-Jan-04 16-Feb-04
4526804 condensor Soldering assy 1 38 16-Feb-04 Active
4519614 Painting Top Cover 1 39 15-Nov-03 Active
4519300 Nut M5 L 1 40 15-Nov-03 Active
433225 Handle 1 41 15-Nov-03 Active
4519607 Left Side Panel Painting Plate 1 42 15-Nov-03 Active
4525080 Discharge Tube 9.53*0.8*470 1 43 15-Nov-03 15-Nov-03
To Next Page
