Electra PXD912 - Page 121

EXPLODED VIEWS & SPARE PARTS LISTS
13-16 SM PXD 1-E.3 GB
13.16 Outdoor Unit: ONG 14 ST
Item Code Item Desc Quantity
Drawing
Number Effective From
Effective
To
433219 Front Panel A1 1 1 01-Mar-04 15-Mar-04
433218 Front Panel A 1 1 15-Mar-04 Active
433221 Air Inlet Ring-420 1 2 01-Mar-04 Active
433223 Painting Insulation Plate 1 3 01-Mar-04 Active
4519251 Axial Fan OD=400 1 4 01-Mar-04 Active
4520171 Fan Motor (910rpm) 1 5 01-Mar-04 Active
4527203 Motor Support 1 6 01-Mar-04 Active
4527255 Base Painting Assy. 1 7 01-Mar-04 Active
4527202 Partition Plate 1 8 01-Mar-04 Active
455000503 Compressor Capacitor With Screw 1 9 01-Mar-04 Active
4519611 Electric Panel Painting Plate 1 10 01-Mar-04 Active
4524176 1/4 Liqiud Valve(R410A) 1 11 01-Mar-04 Active
4524595 1/2 Gas Valve for ONG R410A 1 12 01-Mar-04 Active
455000108 Double patch Capacitor for fan 1 13 01-Mar-04 Active
4514588 5 Poles terminal block 1 14 01-Mar-04 Active
204107 Cable clip Nylon 1 15 01-Mar-04 Active
236179 2 Poles terminal block 1 16 01-Mar-04 Active
4516637 Out sensor Black 1 17 01-Mar-04 Active
4526918 Valve & Capillary Assy 1 19 01-Mar-04 01-Mar-04
4526919 Capillary Assy ID1.6x600 1 19 01-Mar-04 Active
4527362 Charge tube TP2 ¦?6.35x0.8 1 20 01-Mar-04 Active
4527058 Comp. Jacket 1 21 01-Mar-04 Active
4527287 Grommet 3 23 01-Mar-04 Active
4510677 Nut With Flange M8 -D=24 3 24 01-Mar-04 Active
4519987 Wire assy 1 25 01-Mar-04 Active
4526453 Compressor Assy. RN165VHSMT 1 26 01-Mar-04 Active
4527289 Terminal Packing 1 27 01-Mar-04 Active
4527285 Terminal Cover SC01D024 1 28 01-Mar-04 Active
4527286 Terminal Nut 1 29 01-Mar-04 Active
433229 valve cover 1 30 01-Mar-04 Active
433234 Clamp 1 31 01-Mar-04 Active
4519606 Right side panel (painting plate) 1 32 01-Mar-04 Active
4526794 4-way Valve Welding Assy. 1 33 01-Mar-04 01-Mar-04
4526797 Discharge Tube Assy. 1 33 01-Mar-04 Active
4526798 ASuction Tube A 1 34 01-Mar-04 Active
4526911 Distribution Capillary Assy 1 35 01-Mar-04 Active
4526903 Collection tube Assy 1 36 01-Mar-04 Active
433228 Back Side Net 1 37 01-Mar-04 Active
433216 Bridge 1 38 01-Mar-04 Active
4526808 condensor assy 1 39 01-Mar-04 01-Mar-04
4526809 condensor assy 1 39 01-Mar-04 25-Aug-04
4526796 condensor Soldering assy 1 39 25-Aug-04 Active
4519614 Painting Top Cover 1 40 01-Mar-04 Active
4519300 Nut M5 L 1 41 01-Mar-04 Active
433225 Handle 1 42 01-Mar-04 Active
4519607 Left Side Panel Painting Plate 1 43 01-Mar-04 Active
