EXPLODED VIEWS & SPARE PARTS LISTS
13-18 SM PXD 1-E.3 GB
13.18 Outdoor Unit: ONG 14 RC
No. Item Code Item Desc Qty
1 433219 Front Panel A1 1
1 433218 Front Panel A 1
2 433221 Air Inlet Ring-420 1
3 433223 Painting Insulation Plate 1
4 4519251 Axial Fan OD=400 1
5 4519692 Fan Motor (810rpm) 1
5 4520171 Fan Motor (910rpm) 1
6 4527203 Motor Support 1
7 452772500 Base Plate Painting Assy. 1
7 4527255 Base Painting Assy. 1
8 433217 Partition Plate 1
8 4527202 Partition Plate 1
9 455000504 Compressor Capacitor With Screw 1
9 455000503 Compressor Capacitor With Screw 1
10 4519611 Electric Panel Painting Plate 1
10 453013500 Electric Panel Painting Plate 1
11 4524176 1/4 Liqiud Valve(R410A) 1
12 4524177 3/8 Gas Valve(R410A) 1
12 4524595 1/2 Gas Valve for ONG R410A 1
13 455000108 Double patch Capacitor for fan 1
14 4514588 5 Poles terminal block 1
15 204107 Cable clip Nylon 1
16 236179 2 Poles terminal block 1
17 4516637 Out sensor Black 1
19 4526847 Valve-Capillary Assy 1
19 4526918 Valve & Capillary Assy 1
20 4527362 Charge tube TP2 ¦?6.35x0.8 1
21 4527058 Comp. Jacket 1
23 4516357 Rubber Cushion 1K15910311 3
23 4527287 Grommet 3
24 4510677 Nut With Flange M8 -D=24 3
25 4519987 Wire assy 1
26 4526452 Comp. Assy GMCC PA145X2C-4FT 1
26 4526453 Compressor Assy. RN165VHSMT 1
27 4516359 Terminal Packing 1K14720130 1
27 4527289 Terminal Packing 1
28 4516358 Terminal Cover 1K14720012 1
28 4527285 Terminal Cover SC01D024 1
29 4516360 Terminal Nut 1K14300710 1
29 4527286 Terminal Nut 1
30 433229 Valve Cover 1
31 433234 Clamp 1
32 4519606 Right side panel (painting plate) 1
33 4526745 4-way Valve Welding Assy. 1
33 4526794 4-way Valve Welding Assy. 1
35 4526911 Distribution Capillary Assy 1
36 4526903 Collection tube Assy 1
37 433228 Back Side Net 1
38 433216 Bridge 1
38 4526804 condensor Soldering assy 1
38 4526298 Bridge 1
39 4526808 condensor assy 1
39 4526793 condensor Soldering assy 1
40 4519614 Painting Top Cover 1
41 4519300 Nut M5 L 1
42 433225 Handle 1
43 4519607 Left Side Panel Painting Plate 1
