EXPLODED VIEWS & SPARE PARTS LISTS
13-24 SM PXD 1-E.3 GB
13.24 Outdoor Unit: OU7-24 RC 1PH
No. SP No. Part No. Description Qty
1 13 190443 HEATER CRANKCASE MITSUBISHI CO 1
2 22 402283 SUCTION ACCUMULATOR 3"x5/8" 3. 1
3 17 402495 BOARD TPHN 5B 1
4 7 433285 COIL OU7-24 HDR 1
5 15 433288 CAPILLARY ASSY OU7-24 R410A 1
6 16 433291 TUBING ASSY OU7 R410A 1
7 14 433293 COMPRESSOR NN27VBAMT 1
8 6 433294 NEW BASE ASSY OU 2005 EXPORT 1
9 44 433816 SUCTION ASSY OU7 R410A 1
10 9 434062 MOTOR 86W,2S,OU7-24 1
11 19 434716 THERMISTOR+CAP WTH CONNECTOR L 1
12 3 436357 SMALL ELECTRICAL COVER OU 1
13 11 436358 OU LEADING HANDLE 1
14 1 437045 UPPER COVER EL13 OU LARGE 1
15 5 437091 OU SQUARE FAN GUARD 1
16 24 437229 ELECTRICAL BOX TPHN 1
17 21 437274 COMPRESOR WIRING OU7/8-1PH MIT 1
18 4 439329 FRONT COVER/COLLECTOR OU7-35/9 1
19 12 439342 MOTOR SUPPORT OU7 1
20 18 442007 CAPACITOR 6mF 400V P1/P2 1
21 20 442016 CAPACITOR 55mF 400V P1/P2 1
22 33 442466 VALVE COIL L700 MOLEX-SANHUA 1
23 8 4529604 AXIAL FAN D493*143 1
