PRODUCT DATA SHEET
2-7SM PXD 1-E.3 GB
2.7 PXD 24 / OU7-24Z R410A
Model Indoor Unit PXD-24
Model Outdoor Unit OU7-24Z R410A
Installation Method of Pipe Flared
Characteristics Units Cooling Only Cooling Heating
Capacity
(1)
Btu/hr 23300 23300 24000
kW 6.83 6.83 7.03
Power input
(1)
kW 2.27 2.27 2.13
EER (Cooling) or COP(Heating)
(1)
W/W 3.01 3.01 3.03
Energy efficiency class B B C
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 9.7 9.7 8.4
Starting current A 63
Circuit breaker rating A 20
INDOOR
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 1200/980/840
Air flow
(2)
H/M/L m3/hr 1000/900/780
External static pressure Min-Max Pa 0
Sound power level
(3)
H/M/L dB(A) 64/62/59
Sound pressure level
(4)
H/M/L dB(A) 53/51/48
Moisture removal l/hr 2.7
Condensate drain tube I.D mm 16
Dimensions WxHxD mm 1200x630x190
Weight kg 33
Package dimensions WxHxD mm 1270x710x280
Packaged weight kg 38
Units per pallet units 7
Stacking height units 7 levels
OUTDOOR
Refrigerant control Capillary tube +Restrictor
Compressor type ,model Rotary
Fan type & quantity Axial x 1
Fan speeds H/L RPM 850
Air flow H/L m3/hr 3100
Sound power level H/L dB(A) 67
Sound pressure level
(4)
H/L dB(A) 58
Dimensions WxHxD mm 900x680x340
Weight kg 78
Package dimensions WxHxD mm 985x730x435
Packaged weight kg 82
Units per pallet Units 6
Stacking height units 2 levels
Refrigerant type R410A
Refrigerant chargless distance kg/m 2.02kg/15m
Additional charge per 1 meter g/m
Connections between
units
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 5/8"(15.88)
Max .tubing length m. Max.15
Max .height difference m. Max.7
Operation control type LCD Remote control
Heating elements kW
Others
.
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) Airflow in ducted units; at nominal external static pressure.
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
