EXPLODED VIEWS & SPARE PARTS LISTS
13-28 SM PXD 1-E.3 GB
13.28 Outdoor Unit: OU7-24Z RC 1PH
SP No. Part No. Description Qty
44 192207 CONTACTOR 230V, 40A 1
17 413496 BOARD TPHN 5F (RoHS) 1
2 433280 SIDE PANEL OU7-24 R410A 1
10 433281 SIDE GUARD OU7-24 R410 1
7 433285 COIL OU7-24 HDR 1
16 433660 TUBING ASSY OU7-24C R410A 1
6 433722 BASE ASSY OU7-24C EXPORT R410A 1
15 433934 CAPILLARY HEATING ASSY OU7-24 R410A 1
9 434211 replace by SP000000266 MOTOR+BRACKET 1
19a 434716 THERMISTOR L1050 (for coil) 1
3 436357 SMALL ELECTRICAL COVER CUE 1
11 436358 TRANSPORT HANDLE CUE 1
1 437045 LARGE UPPER COVER CUE 1
5 437091 OU SQUARE FAN GUARD 1
24 437229 ELECTRICAL BOX TPHN 1
21 438627 COMPRESSOR WIRING TPHN-5F 1
14 438795 COMPRESSOR GP270PAA 1
4 439329 COVERAIR COLLECTOR 1
12 439342 MOTOR BASE OU7 1
18 442007 CAPACITOR 6uF 400V 1
20 442038 CAPACITOR 50mF 400V P1/P2 1
33 442520 VALVE COIL L700 MOLEX-DUNAN 1
8 4529604 AXIAL FAN D493x143 1
