EXPLODED VIEWS & SPARE PARTS LISTS
13-32 SM PXD 1-E.3 GB
13.32 Outdoor Unit: OU7-24 ST 3PH
No. SP No. Part No. Description Qty
1 1 437045 LARGE UPPER COVER CUE 1
2 2 433280 SIDE PANEL OU7-24 R410A 1
3 3 436357 SMALL ELECTRICAL COVER CUE 1
4 4 439329 COVERAIR COLLECTOR 1
5 5 437091 OU SQUARE FAN GUARD 1
6 6 433705 NEW BASE ASSY OU 2005 LOCAL R410 1
7 7 433846 COIL OU7-24 ST 1
8 8 4529604 AXIAL FAN D493*143 1
9 9 434062 MOTOR 86W,2S,OU7-24 1
10 10 433281 SIDE GUARD OU7-24 R410 1
11 11 436358 TRANSPORT HANDLE CUE 1
12 12 439342 MOTOR BASE OU7 1
13 13 190443 HEATER CRANKCASE MITSUBISHI COMP 1
14 14 433753 COMPRESSOR NN27YDAMT 1
15 15 433845 CAPILLARY ASSY OU7-24 ST R410A 1
16 16 433817 TUBING ASSY OU7 ST R410A 1
17 17 402494 BOARD TPHN 3C 1
18 18 442007 CAPACITOR 6mF 400V P2 1
19 19 434716 THERMISTOR L1050 (for coil) 1
20 21 437278 MITSUBISHI 1
21 22 402283 R410A 1
22 24 437229 ELECTRICAL BOX TPHN 1
23 25 439795 BOARD 3PH PROTECTOR 1
24 44 433816 SUCTION ASSY OU7 R410A 1
25 45 433847 GAS VAVE ASSY OU7 ST R410A 1
SUCTION ACCUMULATOR
